QR10L QR code reader


QR10L is a high-performance QR code reader developed independently by ZKTeco. The reader is compact and could easily read code data from mobiles and printed materials. It could read all available codes with a built-in LED for auxiliary lighting, which has an automatic induction function to read during the day or night without significant impact. The product adopts an international leading intelligent graphic recognition system with strong recognition ability and fast recognition speed.


Scanner Type: QR10L

Material :  Optical

Dimensions (L*W*H)  : QR10L: 75.5 * 53.2 * 20.1 mm

Operating System : Windows, Linux, and Android

Scanning Angle  : Roll: 360°, Pitch: ±40°, Yaw: ±60°

FOV  : Horizontal: 66°, Vertical: 50°

Reading Distance  : 5 to 25 cm

Image Size : 648 * 488 pixels

Illumination Intensity  : 0 to 10000 Lux

One-dimensional Code Types

UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13, EAN-14, EAN-128, UCC128, ISBN/ISSN, CODE11, CODE32, CODE39, CODE39 Full ASCII, CODE93, CODE128, interleaved 2 of 5,

industrial 2 of 5, Matrix 2 of 5, China post code, UK/Plessey, and GS14

Types of QR Code   : QR code, PDF417, Data Matrix, MicroPDF417, and Aztec

Operating Temperature  : -10°C to 50°C

Storage Temperature   : -40°C to 80°C

Operating Humidity  : 5% to 93RH (Non-condensing)

Operating Voltage: USB 5.0V

Operating Current (Working Mode): 240mA

Operating Current (Idle Mode); 50mA

Communication Interface: USB keyboard



Availability: 1 in stock
