HDMI 200M Extender over IP is based on TCP/IP standard. It transmits your HD display with the high resolution up to 200 meters away from your DVD or computer source by using one CAT5e/6 cable.

At the same time, it’s convenient to transmit HDMI audio and video source by point-to-point mode, multipoint-to-multipoint and cascade connection mode

Features:

Support point-to-point mode, multipoint-to-multipoint mode, and cascade connection mode；

802.3 Ethernet standard；

H.264 decode;

Support unilateral IR return signal, control the source on the far end receiver’s side;

IR code compatible with   38 KHz（NEC）

Support USB mouse and keyboard extension；

Support software management during multiple-to-multiple transfers;

HDMI Resolutions.: 480p,720p,1080p;

HDMI Audio: Sample rate:32kHz,44.1kHz and 48kHz code;

The Max Power consumption: HDMI sender:2.5W HDMI receiver:2W

Product dimension: 163*87*24mm

Net weight: 474g x 2

Connection and operation:

Connect the HDMI source (such as DVD, PS3, STB ) to the “HDMI IN” of transmitter by HDMI cable.

Connect the “HDMI out” of Receiver to HDTV display by HDMI cable.

Connect the Transmitter and Receiver with one cat5e/6 cable (recommend).the furthest distance is 200M.

Connect the “IR receiver “into “IR-RX” port on receiver, and “IR transmitter ” into the “IR-TX” on transmitter, and make sure the IR transmitter aim at IR port of the source.

Plug the mouse and keyboard into the USB port of the receiver, and connect the USB port of the transmitter with the computer if you need the KVM control function.

Connect two pieces of 5V power supply to the transmitter and receiver, and power on the HDTV display and HDMI source.

Multi-to-multipoint matching setting: As multiple TX and multiple RX units are connected to switches, you can use management software for pairing management.
